Inner dimensions (wxdxh):                           170 x 200 x 170 mm

Work space¹ (bxtxh):                                     120 x 130 x 120 mm

Outer dimensions (WxDxH):                        390 x 440 x 470 mm

Temperature Uniformity:                              +/- 5 K with closed air inlet in the empty workspace according to DIN 17052-1 at working temperatures > 800°C

Volume:                                                            6 liter

Weight:                                                              18 kg

Power rating:                                                    max. 2,0 kW

Supply voltage:                                               220-240 V 1/N/PE, 50/60 Hz

Max. operating temperature²:                      1100 °C

Heat-up time (without load):                        30 min. to Tmax – 100 K
(if connected at 230 V, 1/N/PE)

1 Defined space inside furnace where the temperature uniformity is valid

2 Continuous operation at maximum temperature can lead to increased wear of the heating elements, thermocouples or isolation. We recommend operation at approx. 50 °C below the maximum temperature.

External dimensions vary depending on additional equipment. Exact dimensions on request.
